BX80677E31275V6 Technical Specifications
Intel Xeon E3-1275V6 / 3.8 GHz processor
Header
Manufacturer :Intel
Brand :Intel
Packaged Quantity :1
Processor
Type :Xeon
Number of Cores :Quad-Core
Number of Threads :8 threads
Processor Number :E3-1275V6
Installed Qty :1
Cache :8 megabyte
Manufacturer :Intel
Clock Speed :3.8 GHZ
Max Turbo Speed :4.2 GHZ
Core Voltage :0.55 V – 1.52 V
Manufacturing Process :14 nm
Thermal Design Power :73 watt
Compatible Processor Socket :LGA1151 Socket
PCI Express Revision :3.0
PCI Express Configurations :1×16, 1×8+2×4, 2×8
PCI Express Lanes Qty :16
Features :Thermal Monitoring Technologies, Intel TSX-NI, Intel Advanced Vector Extensions 2 (AVX2.0), Streaming SIMD extensions 4.2, Intel Virtualization Technology, Intel Device Protection Technology with Boot Guard, Intel 64 Technology, Hyper-Threading Technology, Streaming SIMD extensions 4.1, Intel Trusted Execution Technology, Intel Turbo Boost Technology 2.0, Intel OS Guard, Intel Virtualization Technology for Directed I/O (VT-d), Enhanced SpeedStep technology, Execute Disable Bit capability, Intel Optane Memory Supported, Intel VT-x with Extended Page Tables (EPT), Intel Secure Key, Intel vPro Technology, Intel AES New Instructions (AES-NI), Idle States, Intel Memory Protection Extensions (MPX), Intel Software Guard Extensions (SGX)
Cache Memory Details
Cache Memory Details :Smart Cache – 8 MB
Integrated Graphics
Type :Intel HD Graphics P630
Base Frequency :350 megahertz
Max Dynamic Frequency :1.15 GHZ
Max Supported Memory Size :64 GB
Max Supported Resolution :4096×2304@60Hz (eDP), 4096×2304@60Hz (DP), 4096×2160@24Hz (HDMI)
Features :Intel Clear Video Technology, InTRU 3D Technology, Intel Quick Sync Video, Intel Clear Video HD Technology, Triple Display Capable
Miscellaneous
Product Type :Processor
Processor Package :Intel Boxed
