D-02725-XSJA1 Technical Specifications
NetScout nGenius Decryption Appliance nDA-2725
Category: Cable network testers
Description: NetScout nGenius Decryption Appliance nDA-2725 – Decryption appliance – 4 ports – 10 GigE – 1U – rack-mountable
Manufacturer: NetScout
Dimensions & Weight / Depth: 65 cm
Dimensions & Weight / Height: 4.3 cm
Dimensions & Weight / Weight: 17.24 kg
Dimensions & Weight / Width: 43.7 cm
Header / Brand: NetScout
Miscellaneous / Product Color: Black
Networking / Connectivity Technology: Wired
Networking / Data Link Protocol: 10 Gigabit Ethernet, Gigabit Ethernet
Networking / Form Factor: Rack-mountable
Networking / Ports Qty: 4
Networking / Type: Decryption appliance
Packaged Quantity: 1
Humidity Range Operating: 8 – 90% (non-condensing)
Max Operating Temperature: 35 °C
Min Operating Temperature: 5 °C
Interfaces: 2 x 1Gb Ethernet/10Gb Ethernet – SFP+, 2 x monitoring – SFP28, 2 x 1 Gigabit Ethernet/10Gb Ethernet (management) – RJ-45, 1 x IPMI – RJ-45
Depth: 65 cm
Device Type: Decryption appliance
Height: 4.3 cm
Height (Rack Units): 1U
Weight: 17.24 kg
Width: 43.7 cm
Compliant Standards: UL, EN 61000-3-2, EN 61000-3-3, EN55024, CB, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, RSA, CAN/CSA C22.2 No. 60950, VCCI Class A, EAC, CCC Class A, SSL v3, BIS, TLS v1.2, TLS v1.0, TLS v1.1, EN 55032 Class A, CM
Included Accessories: Rack mount kit
Connectivity Technology: Wired
Data Link Protocol: Gigabit Ethernet, 10 Gigabit Ethernet
Encryption Algorithm: DES, Triple DES, RSA, RC4, MD5, DH, SHA-1, TLS 1.0, SSL 3.0, DSA, 128-bit AES, 256-bit AES, AES-CBC, SHA-2, AES-GCM, TLS 1.1, TLS 1.2, Camellia, DHE, TLS 1.3, SHA-256, SHA-384, SHA-512, SHA-224
Features: Syslog support, manageable, password protection
Form Factor: Rack-mountable
Network / Transport Protocol: TCP/IP, NTP
Ports Qty: 4
Remote Management Protocol: SNMP 2, SNMP 3, HTTP, NTP
Power Consumption Operational: 400 Watt
Power Device: Internal power supply
Power Provided: 750 Watt
Voltage Required: AC 100-140/200-240 V (50/60 Hz)
Hard Drive: HDD 8 TB x 4
Hard Drive (2nd): SSD 1
Processors Installed: 1 x Intel Xeon 6152 2.1 GHz
RAM: 96 GB
