GRHH8 DELL Lsi Megaraid 9285cv-8e 6gb/s Sas Sata Raid Controller

GRHH8 Technical Specifications

DELL Lsi Megaraid 9285cv-8e 6gb/s Sas Sata Raid Controller

Part Number : Grhh8
Manufacturer : Dell
Specification
Product Type: Sas Controller
Controller Interfaces Type: Serial Attached Scsi (sas) . Serial Ata/600
Bus Type: Pci Express 2.0 X8
Data Transfer Rate: Up To 6gb/s Per Port
Raid Supported: Yes
Raid Levels: raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Drive Supported: 64 X Logical . Up To 240
Supported Devices: Hard Drive, Disk Array (raid), Solid State Drive
Platform Supported: Pc . Sparc
Data Backup Type: Battery Backup
Cache Protection: Megaraid Cachevault Flash Cache Protection (included)
Ports: 2 X Sff-8088 6gb/s Sas – Mini-sas
