Lsi9200-8e Technical Specifications
LSI Logic 6gb 8port Ext Pci-express 2.0 X8 Sata/sas Host Bus Adapter
Manufacturer : LSI Logic
Manufacturer Part # LSI9200-8E
Product Type : Host Bus Adapter
I/o Controller : Lsi Sas2008/ Fusion Mpt 2.0
Storage Connectivity Data Transfer Rates : 8 Ports 6gb/s Sas 2.0 Compliant
Host Bus : X8 Lane, Pci Express 2.0 Compliant
Pci Data Burst Transfer Rates : Half Duplex
x8, Pcie, 4000 Mb/s
+12v ±10%
p Hysical Dimensions : Low Profile (2. 6” X 6.6”)
Cable Support : Passive Copper
Pci Card Type : 3.3 V Add-in Card
Operating Voltage : +12v +/-8% 3.3v +/-8%
Pci Power (nominal) : 8 W Typical (airflow Min 200 Lfm)
Device Support : 512 Non-raid Sas/sata Devices
