MS130-24P-HW Technical Specifications
Cisco MS130-24P 24x RJ45 PoE+ 4x SFP Managed GbE Switch
Part Number: MS130-24P-HW
Series: Cisco Meraki MS130 Series
Type: Layer 2 Cloud-Managed PoE+ Switch
Total Ports: 28
Gigabit Ethernet Ports: 24 x 10/100/1000 RJ-45 PoE+
Uplink Ports: 4 x 1G SFP
Switching Capacity: 128 Gbps
Forwarding Rate: 95.2 Mpps
MAC Address Table: 16,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
PoE Standard: IEEE 802.3af/at (PoE+)
PoE Budget: 370W max
Stacking Capability: Not supported
Spanning Tree Protocols: STP, RSTP, MSTP
Link Aggregation: IEEE 802.3ad LACP
Quality of Service: 8 Queues, IEEE 802.1p, DSCP
Security: 802.1X, ACLs, Port Security, DHCP Snooping
Management: Meraki Cloud Dashboard (Web-based)
Port Mirroring: Supported
LED Indicators: Power, System, Link/Activity, PoE
Form Factor: 1U Rack-mountable
