R8Q72A HPE Aruba 12x RJ45 PoE Class4 2G/2x SFP+ GbE Switch
R8Q72A Overview
The HPE Aruba 6000 Series R8Q72A is a compact enterprise-class Layer 3 managed switch engineered for modern edge and branch networking environments. It comes with 12 Gigabit RJ-45 ports that provide Class 4 PoE+ power, delivering up to 30W per port and a total PoE power budget of 139W. This makes it well-suited for powering IP phones, wireless access points, and surveillance cameras directly from the switch.Alongside its access ports, the switch is equipped with 2 dedicated RJ-45 uplinks and 2 SFP+ uplinks that support 1/10Gb speeds, ensuring flexibility for both copper and fiber uplinks and allowing seamless connectivity to distribution or core switches.
R8Q72A Technical Specifications
HPE Aruba 12x RJ45 PoE Class4 2G/2x SFP+ GbE Switch
Manufacturer: HPE Aruba
Manufacture Part Number: R8Q72A
Ports: 12 x RJ-45 Gigabit Ethernet (10/100/1000Base-T)
PoE Support: Class 4 PoE+ (up to 30W per port)
PoE Power Budget: 139W total
Uplink Ports: 2 x RJ-45 Gigabit + 2 x SFP+ (1/10Gb)
Total Ports: 16 (12 RJ-45 + 2 RJ-45 uplink + 2 SFP+)
Switching Capacity: 80 Gbps
Forwarding Rate: 59.5 Mpps
Layer: Layer 3 Managed
Form Factor: 1U Rack-mountable
Management: Web GUI, CLI, REST API, SNMP
Resiliency: VRRP, RSTP, MSTP
Energy Efficiency: Smart PoE, low power consumption
