SRW208P-K9 Technical Specifications
Cisco Small Business 8-Ports RJ-45 10/100 PoE Layer 3 Manageable Rack-mountable with Combo Gigabit SFP Switch
Manufacturer: Cisco
Manufacturer Part Number: SRW208P-K9
Series: Small Business 200 Series
Type: Layer 3 Managed PoE Switch
Ports: 8 x 10/100Base-T RJ-45
PoE Support: Yes, IEEE 802.3af
Uplink Ports: 2 x Combo RJ-45/SFP
Switching Capacity: 6 Gbps
Forwarding Rate: 4.46 Mpps
Layer Support: Layer 3
Management: Web GUI, CLI, SNMP v1/v2/v3
VLAN Support: 64 VLANs (802.1Q)
QoS: 802.1p priority, traffic shaping
Security: 802.1X, ACLs, port security
MAC Address Table: 8K entries
Jumbo Frames: Supports up to 9K bytes
Resiliency: STP, RSTP, MSTP supported
Form Factor: Desktop, Wall-mountable, Rack-mountable
Rack Mount: 1U supported
Auto MDI/MDIX: Supported
Duplex Mode: Half/Full duplex
Flow Control: IEEE 802.3x compliant
LED Indicators: Power, link/activity, speed, PoE status
Power Supply: Internal AC power supply
