SSG-520M-SH-N-TAA Juniper Secure Services Gateway SSG 520M

In Stock

SSG-520M-SH-N-TAA Overview

The Juniper Networks Secure Services Gateway 500 Series (SSG) represents a new class of purpose-built security appliance that delivers a perfect mix of performance, security and LAN/WAN connectivity for regional and branch office deployments. A complete set of Unified Threat Management (UTM) security features including Stateful firewall, IPS, Antivirus (includes Anti-Spyware, Anti-Adware, Anti-Phishing), Anti-Spam, and Web Filtering allow the SSG 500 Series to be implemented as standalone security devices to stop worms, Spyware, Trojans, malware and other emerging attacks. Complementing the powerful UTM security features is a robust routing engine that allows the SSG 500 Series to be deployed as a traditional branch office router or as a combination firewall and routing device to reduce capital and operational expenses.



SSG-520M-SH-N-TAA Technical Specifications

Juniper Networks Secure Services Gateway SSG 520M security appliance

Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks Secure Services Gateway
Model :SSG 520M
Packaged Quantity :1
Built-in Devices :LED panel
Installed Size :1 GB
Optical Storage
Type :None
Performance :Firewall throughput (large packets): 650+ Mbps, 3DES throughput: 300 Mbps, Firewall throughput (IMIX): 600 Mbps
Capacity :Security zones: 60, VPN tunnel interfaces: 100, Concurrent VPN tunnels: 500, Authenticated users (internal database): 1500, Connection / user qty: unlimited, Concurrent sessions: 64000, Security policies: 1000, Static routes: 20000
Type :Security appliance
Form Factor :External
Connectivity Technology :Wired
Data Link Protocol :Ethernet, PPP, HDLC, Gigabit Ethernet, Frame Relay, Fast Ethernet, MLPPP, FRF.15, FRF.16
Routing Protocol :IGMP, PIM-SM, RIP-1, BGP, RIP-2, PIM-SSM, OSPF, IGMPv2, Static IP routing
Network / Transport Protocol :L2TP, NetBEUI/NetBIOS, PPPoE, IPSec
Remote Management Protocol :HTTP, SNMP, HTTPS, SNMP 2, Telnet
Status Indicators :Receive, Status, Port status, Power, Transmit, Alarm, Link/activity
Features :PAT support, DHCP support, DoS attack prevention, NAT support, DDos attack prevention, 56-bit encryption, High Availability, Routing, LDAP support, Firmware upgradable, Transparency, Firewall protection, VPN support, Syslog support, Modular design, 168-bit encryption, URL filtering, DiffServ support, Quality of Service (QoS), VLAN support
Compliant Standards :IEEE 802.1x, X.509
IP Telephony
VoIP :Yes
VoIP Protocols :SCCP, H.323, SIP, MGCP
Expansion Slots
Expansion Slots :4, 6 (total) / 6 (free) x expansion slot
Interface Provided
Interfaces :1 x management, 4 x 1000Base-TX, 1 x management – RJ-45
OS Provided
Type :ScreenOS
Power Device
Type :Internal power supply
Power Provided :350 watt
Nominal Voltage :AC 120/230 V
Frequency Required :50/60 hertz
TAA Compliant :Yes
Height (Rack Units) :2
Encryption Algorithm :PKI, AES, MD5, Triple DES, RSA, DES, IKE, SHA-1
Authentication Method :SecurID, RADIUS, LDAP, Secure Shell v.2 (SSH2), X.509 certificates
Compliant Standards :C-Tick, NEBS level 3, cUL, VCCI Class A ITE, UL, FCC Class B certified, CSA, CB, BSMI
Dimensions & Weight
Width :17.4 inch
Depth :21.1 inch
Height :3.4 inch
Weight :22.93 lbs
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :122 degree Fahrenheit
Humidity Range Operating :10 – 90%
