ST10000NM013G Technical Specifications
Seagate Exos X18 10TB SAS 12Gbps 256MB 3.5-inch Hard Drive
Brand Seagate
Product Line Seagate Exos X18
Model ST10000NM013G
Manufacturer Seagate Technology
Storage
Average Latency 4.16 millisecond
Buffer Size 256 megabyte
Data Transfer Rate (Hard Drive) 1.2 GBps
Hard Drive Capacity 10 TB
Hard Drive Features
Advanced format 4Kn, Advanced format 512e, Conventional magnetic recording (CMR), Dual Port, Helium Sealed-Drive Design, Hot-Plug Support, Low Halogen, Organic Solderability Preservative, Power Balance, Power Choice, Seagate Fast Format, Super Parity, T10 Data Integrity Field (DIF)
Hard Drive Type
Internal hard drive
HD Interface
Serial Attached SCSI 3
Max Internal Data Transfer Rate 270 MBps
Non-Recoverable Errors 1 per 10^15
Spindle Speed (rpm)
7200 revolutions per minute
Storage Interface
Serial Attached SCSI 3
Connectivity
Interface Provided 1 x SAS 12 Gb/s
Display & Graphics
Touchscreen No
Power
Power Consumption 4.9 Watt (idle), 5.9 Watt (random read/write), 9 Watt (maximum)
Technical Information
Max Operating Temperature
140 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
MTBF 2,500,000 Hours
Shock Acceleration (Non-operating) 200 gram
Shock Acceleration (Operating) 50 gram
Shock Duration (Non-operating) 2 ms
Shock Duration (Operating) 2 ms
Vibration Acceleration (Non-operating) 2.27 gram
Vibration Frequency Range (Non-operating) 2-500 Hz
Product Information
Packaged Quantity 1
Product Type Hard drive
Service Activation No
Dimensions & Weight
Height 1 inch
Weight 22.93 ounce
Width 4 inch
Depth 5.8 inch
