EX2300-48T Technical Specifications
Juniper Networks EX Series switch 48 ports managed rack mountable
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks EX Series
Model
Packaged Quantity :1
Processor
Installed Qty :1
Manufacturer :ARM
Clock Speed :1.25 GHZ
RAM
Installed Size :2 GB
Flash Memory
Installed Size :2 GB, 2 GB
Performance
Performance :Switching capacity: 176 Gbps, Throughput: 130 Mbps
Capacity
Capacity :Multiple Spanning Tree Protocol instances: 64, IPv6 routes (Unicast): 512, IPv4 hosts: 4096, VLAN Spanning Tree Protocol instances: 253, IPv6 hosts: 2048, Maximum member ports per LAG: 8, IPv6 routes (Multicast): 1024, LAG groups: 128, IPv4 route prefixes: 1500, Maximum of neighboring networks: 1500, IPv4 routes (Multicast): 2048, Virtual interfaces (VLANs): 4093, QoS hardware queues per port: 8, ARP entries: 1500, ACL entries: 2000
Networking
Type :Switch
Subcategory :Network hubs and switches
Subtype :Gigabit Ethernet
Form Factor :Rack-mountable, Desktop
Ports Qty :48
Advanced Switching :Layer 3
Routing Protocol :CIDR, RIPng, Static IPv6 routing, Static IPv4 routing, RIP-2, RIP-1, OSPFv3
MAC Address Table Size :16000 entries
Jumbo Frame Support :9216 bytes
Manageable :Yes
Remote Management Protocol :RMON 3, RMON 1, HTTPS, SNMP 1, Telnet, RMON 9, CLI, SNMP 2c, HTTP, RMON 2, SNMP 3, SNMP, TFTP, SSH
Features :Access Control List (ACL) support, VLAN Spanning Tree Protocol (VSTP), DHCP server, Store and forward, Auto-uplink (auto MDI/MDI-X), Cable Diagnostics Function, Class of Service (CoS),
