SG500-28P-K9-G5 Cisco Small Business SG500-28P Managed Switch

SG500-28P-K9-G5 Technical Specifications

Cisco Small Business SG500-28P Managed Switch

Product Line Cisco Small Business
Product Series SG500
Device Type: Switch – 28 ports – Managed – stackable
Enclosure Type: Rack-mountable
Subtype: Gigabit Ethernet
Ports: 24 x 10/100/1000 + 2 x combo Gigabit SFP + 2 x SFP
Power Over Ethernet (PoE): PoE
Routing Protocol: Static IP routing
Features: Flow control, Layer 2 switching, VLAN support, IPv6 support, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol: (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), reset button, LACP support, Energy Efficient Ethernet, Dynamic VLAN Support (GVRP)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az
RAM: 256 MB
Flash Memory: 32 MB
Status Indicators Port transmission speed, system, PoE, link/activity
Expansion / Connectivity
Interfaces 26 x 1000Base-T RJ-45 PoE
2 x 1000Base-T RJ-45
4 x SFP (mini-GBIC)
Power
Power Device Internal power supply
Voltage Required AC 120/230 V (50/60 Hz)
Miscellaneous
Cables Included 1 x serial cable
Compliant Standards UL 60950, FCC Part 15 A, CSA 22.2
Localisation Europe
Dimensions & Weight
Width 44 cm
Depth 25.7 cm
Height 4.4 cm
Weight 4 kg
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 10 – 90% (non-condensing)
Min Storage Temperature -20 °C
Max Storage Temperature 70 °C
Humidity Range Storage 10 – 90% (non-condensing)
