641016-B21 Technical Specifications
HP Proliant Bl460c G8 CTO Chassis With No CPU No RAM Matrox G200 Gigabit Ethernet 10 Gigabit Ethernet 2-Way Blade Server.
GENERAL INFORMATION :
Manufacturer : Hewlett Packard
Manufacturer Part Number : 641016-B21
Product Name : Proliant Bl460c G8 Blade Server
PROCESSOR & CHIPSET :
Processor Type : None
Max Supported Qty : 2
Upgradability : Upgradable
Chipset Type : Intel C600
MEMORY :
Installed Size : None
Maximum Size : 512 Gb
Technology : Ddr3 Sdram
Form Factor : Dimm 240-Pin
Features : Quad Channel Memory Architecture, Hp Smartmemory
Ram Supported : Pc3-12800 – 512 Gb – Registered Pc3-10600 – 128 Gb – Unbuffered – Advanced Ecc
STORAGE & STORAGE CONTROLLER :
Hard Drive : None
Storage Controller Type : 1 X SAS Serial Attached Scsi 2 Integrated – Pci Express X4
Controller Interface Type : Serial SAta-300 / Sas 2.0
Storage Controller Name : Smart Array P220i With 512mb Fbwc
Raid Level : Raid 0, Raid 1
Buffer Size : 512 Mb
DISPLAY & GRAPHICS CONTROLLERS :
Graphics Controller Type : Integrated
Graphics Processor : Matrox G200
NETWORK & COMMUNICATION :
Networking : Network Adapter – Pci Express 2.0 X8 – Integrated
Ethernet Ports : 2 X 10 Gigabit Ethernet
Data Link Protocol : Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol : Snmp, Ipmi 2.0, Smash Clp
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol)
Compliant Standards : Ieee 802.1q, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.3ap
EXPANSIONS & CONNECTIVITY :
Expansion Bays Total (Free) :
2 (Total) / 2 (Free) X Hot-Swap – 2.5in Sff
EXPANSION SLOTS TOTAL (FREE) :
2 (Total) / 2 (Free) X Processor
16 (Total) / 16 (Free) X Memory – Dimm 240-Pin
2 Expansion Slot
1 (Total) / 1 (Free) X Sd Memory Card
INTERFACES & PORTS :
1 X Management – Hp Ilo – Rj-45
2 X Network – Ethernet 10gbase-Kr – Rj-45
