7X04A083NA Lenovo ThinkSystem SR550 – rack-mountable

7X04A083NA Overview

SR550 offers numerous features to increase performance and flexibility. It features two Intel Xeon Scalable family CPUs, with 43 percent more cores, faster memory, increased I/O, and more storage capacity than the previous generation. SR550 is available with big storage, a 50 percent increase. Software and hardware RAID with simple-swap hard drives make it easy to manage storage needs. SR550 also supports two internal M.2 boot drives, freeing up the other drive bays for additional storage capacity. Front USB 3.0 ports and optional front VGA simplify deployment and servicing. Plus, up to six PCIe adapter slots and several choices of optional 1GbE/10GbE LOM and NICs, 80 PLUS Platinum and Titanium PSUs, and continuous operation at 45°C, provide additional flexibility and cost savings.

$4,119

Buy Now
Availability: In Stock
SKU:7X04A083NA
Brand:

7X04A083NA Technical Specifications

Lenovo ThinkSystem SR550 – rack-mountable

Processor
Clock Speed :2.1 GHz
Installed Qty :1
Manufacturer :Intel
Max Supported Qty :2
Max Turbo Speed :3.2 GHz
Number of Cores :16-core
Processor Main Features :Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Virtualization Technology
Processor Number :4216
Server Scalability :2-way
Type :Xeon Bronze
Audio Input
Type :None
Bay Provided
Form Factor :3.5″
Free Qty :12
Total Qty :12
Cache Memory
Installed Size :22 MB
Installed Size :22
Per Processor Size :22 MB
Per Processor Size :22
Display
Type :None.
Header
Brand :Lenovo
Country Kits :North America
Manufacturer :Lenovo System X
Model :7X04
Packaged Quantity :1
Product Line :Lenovo ThinkSystem SR550
Interface Provided
Connector Type :RJ-45
Type :Management
Location :1 front, 2 rear
Qty :3
Type :USB 3.0
Location :1 in front
Qty :1
Type :USB 2.0
Qty :2
Type :LAN (Gigabit Ethernet)
Type :VGA
Mainboard
Chipset Type :Intel C622
Miscellaneous
Color Category :Black
Compliant Standards :AS/NZS CISPR 22, CB, CISPR 22 Class A, FCC Part 15 A, GB 17625.1, GB 4943.1, GB 9254 Class A, GOST ME01, GOST-R 51317.3.2, GOST-R 51317.3.3, GOST-R 51318.22, GOST-R 51318.24, ICES-003 Class A, IEC60950-1, KN22 Class A, KN24, NMB-3 Class A, NOM-019, RoHS, TUV GS, UL/CSA60950-1, VCCI Class A
Height (Rack Units) :2
Included Accessories :Tool-less rail kit
Networking
Data Link Protocol :Gigabit Ethernet
Ethernet Ports :2 x Gigabit Ethernet
Remote Management Controller :XClarity Controller (XCC) Enterprise
