Home›Transceivers›HP Transceiver›868243-001 HP 40Gbps 40GBase-BIDI 100m Duplex LC Connector QSFP+ Transceiver Module
HP-868243-001

868243-001 HP 40Gbps 40GBase-BIDI 100m Duplex LC Connector QSFP+ Transceiver Module

868243-001 Overview

The HP 868243-001 is a 40-Gigabit Ethernet QSFP+ bidirectional optical transceiver optimized for short-reach, high-bandwidth data center links over multi-mode fiber. Leveraging bidirectional (BiDi) transmission technology, it enables full 40Gbps data throughput over just two fibers (one pair), drastically reducing fiber count and simplifying cabling. Operating on the 850nm wavelength range with WDM multiplexing, it supports distances of up to 100 meters on OM3 fiber and 150 meters on OM4 fiber. It features a standard duplex LC connector, making it easy to deploy within existing MMF infrastructures. This hot-swappable module supports Digital Optical Monitoring (DOM) for real-time diagnostics such as temperature, transmit power, and receive power.

Availability: In Stock
SKU:868243-001
Brand:

868243-001 Technical Specifications

HP 40Gbps 40GBase-BIDI 100m Duplex LC Connector QSFP+ Transceiver Module

Manufacturer Part Number: 868243-001
Brand Name: HP
Product Type: QSFP+ Transceiver
Data Rate: 40Gbps
Transceiver Type: 40GBase-BIDI (Bidirectional)
Media Type Supported: Multi-Mode Fiber (MMF)
Wavelength: 850nm / 910nm BiDi operation
Connector Type: Duplex LC
Maximum Reach: Up to 100m (OM3) / 150m (OM4)
Form Factor: QSFP+
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 2 (duplex)
Compatibility: HP networking equipment with QSFP+ ports
Application: Data center and enterprise aggregation links
Special Feature: Enables 40G over two fibers instead of eight
Standards Compliance: IEEE 802.3ba, MSA
Operating Temperature: 0°C to 70°C
