Home›Transceivers›Juniper Transceivers›BP3AM4CL-04 Juniper 10Gbps 10GBase-CWDM Single-mode Fiber Transceiver Module
Juniper-BP3AM4CL-04

BP3AM4CL-04 Juniper 10Gbps 10GBase-CWDM Single-mode Fiber Transceiver Module

BP3AM4CL-04 Overview

The Juniper BP3AM4CL-04 is a 10Gbps CWDM (Coarse Wavelength Division Multiplexing) XFP optical transceiver module, purpose-built for long-haul 10GBase-CWDM Ethernet and transport applications. Designed for single-mode fiber (SMF), it delivers long-distance connectivity up to 80 kilometers, making it ideal for metropolitan networks, carrier backbones, and data center interconnects (DCI).Operating at a 1551nm CWDM wavelength, this module allows network operators to maximize fiber efficiency by transmitting multiple channels over a single fiber pair, significantly reducing infrastructure costs. It uses a duplex LC optical connector, ensuring precise, low-loss optical links while maintaining compatibility with industry-standard SMF cabling.

Availability: In Stock
SKU:BP3AM4CL-04
Brand:

BP3AM4CL-04 Technical Specifications

Juniper 10Gbps 10GBase-CWDM Single-mode Fiber 80km 1551nm LC Connector XFP Transceiver Module

Manufacturer Part Number: BP3AM4CL-04
Brand Name: Juniper Networks
Product Type: XFP Transceiver Module
Data Rate: 10Gbps
Transceiver Type: 10GBase-CWDM
Media Type Supported: Single-Mode Fiber (SMF)
Wavelength: 1551nm CWDM
Connector Type: LC Duplex
Maximum Reach: Up to 80km over SMF
Form Factor: XFP
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 2 (duplex)
Compatibility: Juniper Networks routers and switches with XFP slots
Application: Metro networks, long-haul, and enterprise backbone connectivity
Standards Compliance: IEEE 802.3ae 10GBASE-CWDM, XFP MSA compliant
Backward Compatibility: Interoperable with standard CWDM optical systems
Operating Temperature: 0°C to 70°C (standard range)
Power Consumption: Low power design for efficiency
