C1000-24FP-4G-L Technical Specifications
Cisco Catalyst 1000 with 24 Port PoE+370W 4 SFP Uplink
Product Line: Cisco Catalyst
Product Series: C1000
Hardware
24 Port Network Switch
Interface 24x 10/100/1000 Ethernet PoE + ports and 370W PoE budget, 4 SFP uplinks
Ethernet Technology: Gigabit Ethernet
Console ports
1x RJ-45 Ethernet
USB mini-B
USB-A port for storage and Bluetooth console
Indicator LEDs
Per-port status: link integrity, disabled, activity
System status: system
Dimensions (WxDxH in inches) 17.5 x 13.59 x 1.73
Weight 4.6
Memory and processor
CPU
ARM v7 800 MHz
DRAM
512 MB
Flash memory
256 MB
Performance
Forwarding bandwidth
28 Gbps
Switching bandwidth
56 Gbps
Forwarding rate
(64 ‑ bytes L3 packets)
41.67 Mpps
Unicast MAC addresses
15,360
IPv4 unicast direct routes
542
