C3945VSECPSREK9 Cisco 3945 Router
C3945VSECPSREK9 Overview
The Cisco 3945 SRE 900 Security Services Fast Ethernet Router offers high-speed network connectivity for large enterprise and service provider networks. It is equipped with a variety of interfaces including Fast Ethernet, Gigabit Ethernet, and 10 Gigabit Ethernet ports. The router also includes the Security Services Processor (SSP) module, which enables advanced security features such as firewall, VPN, and intrusion prevention.
C3945VSECPSREK9 Technical Specifications
Cisco 3945 Router
Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : SNMP, RMON
Encryption Algorithm : SSL
RAM : 1 GB (installed) / 2 GB (max)
Flash Memory : 256 MB (installed) / 8 GB (max)
Hard Drive : 1 TB
Status Indicators : Power, link/activity
Communications
Type : Voice / fax module
Digital Ports Qty : 64
Protocols & Specifications : ITU G.168
IP Telephony:
Voice Codecs : G.711, G.722, G.723.1, G.728, G.729, G.729a, G.729ab, G.726
Expansions And Connectivity
Expansion Slots : 4 (total) / 4 (free) x EHWIC 4 (total) /
Power
Power Device : Internal power supply
Voltage Required : AC 120/230 V (50/60 Hz)
Software / System Requirements
Software Included : Cisco IOS Unified Communications, Cisco IOS Security
