J9575-61001 Technical Specifications
HP 24-Ports SFP+ Gigabit Ethernet Tl Switch
Manufacturer: HP
Manufacturer Part Number: J9575-61001
Ports: 24 x SFP Gigabit Ethernet
Uplinks: SFP+ slots (shared for uplink expansion)
Speed: 1000 Mbps per port (SFP)
Layer: Layer 2 / Lite Layer 3
Management: Web interface, CLI, SNMP
VLAN: IEEE 802.1Q VLAN tagging
QoS: 802.1p traffic prioritization
Security: Access control lists, 802.1X authentication
Switching Capacity: 56 Gbps
Forwarding Rate: Up to 41.6 Mpps
Jumbo Frames: Supported
Hot Swap: Not applicable (fixed switch)
Form Factor: Rack-mountable 1U
LEDs: Port status, activity, link, power
Redundant Power: Optional external RPS support
Cooling: Internal fans, chassis cooling
STP: STP, RSTP, MSTP supported
Multicast: IGMP snooping, MLD snooping
Ease of Use: Flexible fiber-based access switching
