J9776-61001 Technical Specifications
HP ProCurve 2530 24-Ports 10/100/1000 RJ-45 Manageable Layer2 Rack-mountable Desktop Wall-mountable Switch
Manufacturer Part Number: J9776-61001
Brand Name: HP
Product Line: ProCurve 2530 Series
Product Type: Managed Gigabit Ethernet Switch
Total Ports: 28
Gigabit Ethernet Ports: 24 x 10/100/1000Base-T RJ-45
Uplink/Expansion Ports: 4 x Gigabit SFP
Layer Support: Layer 2
Switching Capacity: 52 Gbps
Forwarding Rate: 38.7 Mpps
MAC Address Table: 16,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: IEEE 802.1D, 802.1w, 802.1s
Static Routing: Not Supported
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 Priority Queues, IEEE 802.1p
Security: IEEE 802.1X, ACLs, Port Security
Management: Web GUI, CLI, SNMP v1/v2c/v3
