JG896A Technical Specifications
HP 40-Ports RJ-45 10/100/1000Base-T Manageable Layer 3 Rack-mountable 1U with Gigabit Ethernet QSFP+ Switch
Manufacturer Part Number: JG896A
Brand Name: HP
Product Line: HP 5900AF Series
Product Type: Layer 3 Managed Gigabit Ethernet Switch
Total Ports: 40
Gigabit Ethernet Ports: 40 x 10/100/1000Base-T RJ-45
Uplink/Expansion Ports: 2 x QSFP+ (40GbE)
Layer Support: Layer 2 / Layer 3
Switching Capacity: 336 Gbps
Forwarding Rate: 250 Mpps
MAC Address Table: 128,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: IEEE 802.1D, 802.1w, 802.1s
Static Routing: IPv4 / IPv6 Supported
Dynamic Routing: OSPF, BGP, RIP Supported
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 Priority Queues, IEEE 802.1p, DSCP
Security: IEEE 802.1X, ACLs, Port Security, DHCP Snooping
Management: Web GUI, CLI, SNMP v1/v2c/v3, RMON
Port Mirroring: Supported
