JL169A Technical Specifications
HP 6-Ports SFP+ Manageable Layer 2 Rack-Mountable Gigabit Ethernet Switch
Manufacturer Part Number: JL169A
Brand Name: HP
Product Line: HP 1910 / 1920 Series (depending on exact SKU)
Product Type: Layer 2 Managed Gigabit Ethernet Switch
Total Ports: 6
Gigabit Ethernet Ports: 6 x SFP+ (1GbE/10GbE fiber ports)
Uplink/Expansion Ports: Not Applicable (SFP+ ports serve as uplinks)
Layer Support: Layer 2
Switching Capacity: 12 Gbps
Forwarding Rate: 8.9 Mpps
MAC Address Table: 8,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Spanning Tree Protocols: IEEE 802.1D, 802.1w, 802.1s
Static Routing: Not Supported
Dynamic Routing: Not Supported
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 Priority Queues, IEEE 802.1p
Security: IEEE 802.1X, ACLs, Port Security
Management: Web GUI, CLI, SNMP v1/v2c/v3
RMON Monitoring: 4 Groups Supported
