Home›Network Switches›HP Network Switch›JL479-61101 HP 8320 Aruba SFP+ 48-P 6-P + L3 QSFP+ Switch
HP-JL479-61101

JL479-61101 HP 8320 Aruba SFP+ 48-P 6-P + L3 QSFP+ Switch

JL479-61101 Overview

The HP JL479-61101 Aruba 8320 Switch is a high-performance, enterprise-class, Layer 3 modular switch designed for data center top-of-rack (ToR), aggregation, and large campus core deployments. It provides a combination of 48 SFP+ 10-Gigabit Ethernet ports and 6 QSFP+ 40-Gigabit uplinks, delivering the scalability and performance required for modern applications, virtualization, and cloud environments.With its non-blocking switching fabric and high throughput architecture, the switch enables line-rate performance across all interfaces, supporting intensive east-west and north-south traffic patterns common in virtualized and cloud-driven data centers.

Availability: In Stock
SKU:JL479-61101
Brand:

JL479-61101 Technical Specifications

HP 8320 Aruba SFP+ 48-P 6-P + L3 QSFP+ Switch

Manufacturer Part Number: JL479-61101
Brand Name: HP
Product Type: Layer 3 Managed Switch
Total Ports: 48
Port Type: 48 x SFP+ (10GbE) + 6 x QSFP+ (40GbE)
Layer Support: Layer 3
Switching Capacity: 2.5 Tbps
Forwarding Rate: 1,905 Mpps
MAC Address Table: 128,000 entries
VLAN Support: 4,094 VLANs
Spanning Tree Protocols: IEEE 802.1D, 802.1w, 802.1s
Routing: IPv4 / IPv6 supported
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service: 8 queues, IEEE 802.1p, DiffServ
Security: 802.1X, ACLs, Port Security
Management: Web GUI, CLI, SNMP
Stacking Capability: VSX supported
Form Factor: 1U Rack-mountable
Power Supply: Dual hot-swappable AC PSU
Compliance: RoHS
