P13658-X21 Technical Specifications
HPE 480GB DS Serial Advanced Technology Attachment (SATA) 6GBPS Mixed Use 2.5 Inch Internal Solid State Drive
Manufacturer Name: HPE
MPN: P13658-X21
Type: Solid State Drive
SSD Type: SATA 6GBPS
Technical Information
Capacity: 480 GB
Form Factor: 2.5 Inch SFF
Interface: SATA 6GBPS
NAND Flash Memory Type: Triple-level cell (TLC)
Connectivity: Single Port
Plug Type: Hot Pluggable
Carrier Type: Smart Carrier (SC)
Workload Type: Mixed Use
Features: Digitally Signed Firmware (DS)
Bundled with: HPE Smart Carrier (SC)
Expansion & Connectivity
Interfaces: 1 x SATA 6 GB/S
Compatible Bay: 2.5 Inch SFF
Power
Idle Time: 1.14 Watt
Random Read: 2.34 Watt
Random Write: 2.34 Watt
Sequential Read: 3.56 Watt
Sequential Write: 3.44 Watt
Random Read/Write: 2.34 Watt
Maximum: 3.56 Watt
Dimensions & Weight
Height: 0.63 Inch
Width: 3.10 Inch
Depth: 5.45 Inch
Weight: 1.50 Lbs
