P20199-H21 Technical Specifications
HPE 6.4TB PCI-Express NVMe Gen4 Mixed Use Mainstream Performance Digitally Signed CD6 SFF SC U.3 Solid Sate Drive (SSD)
Brand: HPE (Hewlett Packard Enterprise)
Model: P20199-H21
Capacity: 6.4TB
Interface: PCI Express 4.0 x4 (NVMe)
Form Factor: 2.5-inch Small Form Factor (SFF)
Connector Type: U.3 Universal Interface
Drive Type: Mixed Use (MU)
Performance Class: Mainstream Performance
Series / Controller: CD6 Series
Firmware Type: Digitally Signed Firmware (DS)
Data Transfer Rate: Up to 32Gbps (PCIe Gen4 x4)
Sequential Read Speed: Up to 7,000 MB/s
Sequential Write Speed: Up to 4,200 MB/s
Random Read (4K): Up to 1,000,000 IOPS
Random Write (4K): Up to 300,000 IOPS
Endurance: 3 DWPD (Drive Writes Per Day)
NAND Flash Type: 3D TLC NAND
Latency (Read/Write): <0.1 ms / <0.2 ms typical
Power Consumption (Active): ~12W typical
Power Consumption (Idle): ~4.5W typical
MTBF (Reliability): 2 Million Hours
Hot-Pluggable: Yes
