P20203-S21 Technical Specifications
HPE 1.6TB PCI Express Gen4 NVMe Read Intensive U.3 2.5-inch Internal Solid State Drive (SSD) with Smart Carrier
Brand: HPE (Hewlett Packard Enterprise)
Model: P20203-S21
Capacity: 1.6TB
Interface: PCI Express Gen4 x4 (NVMe)
Form Factor: 2.5-inch Small Form Factor (SFF)
Connector Type: U.3 Universal Interface
Drive Type: Read Intensive (RI)
Performance Class: Mainstream Performance
Carrier Type: Smart Carrier (SC) with LED indicators
Data Transfer Rate: Up to 32Gbps (PCIe Gen4 x4)
Sequential Read Speed: Up to 7,000 MB/s
Sequential Write Speed: Up to 3,500 MB/s
Random Read (4K): Up to 900,000 IOPS
Random Write (4K): Up to 100,000 IOPS
Endurance: 1 DWPD (Drive Write Per Day)
NAND Flash Type: 3D TLC NAND
Latency (Read/Write): <0.1 ms / <0.2 ms typical
Power Consumption (Active): ~10W typical
MTBF (Reliability): 2 Million Hours
Encryption / Security: Digitally Signed Firmware (DS)
Hot-Pluggable: Yes
