PRIME A320M-K Technical Specifications
ASUS Ryzen AM4 DDR4 HDMI VGA M.2 Micro-ATX A320 Motherboard
Model
Brand
ASUS
Model
Prime A320M-K
Supported CPU
CPU Socket Type
AM4
CPU Type
AMD AM4 Socket Ryzen with Radeon Vega Graphics / Ryzen 1st Generation / 7th Generation A-series /Athlon X4 Processors
Chipsets
Chipset
AMD A320
Memory
Number of Memory Slots
2×288pin
Memory Standard
AMD Ryzen with Radeon Vega Graphics/ Ryzen 1st Generation Processors
DDR4 3200(O.C.)/ 2933(O.C.)/ 2666/ 2400/ 2133
AMD 7th Generation A-Series/ Athlon X4 Processors
DDR4 2400/ 2133
* Hyper DIMM support is subject to the physical characteristics of individual CPUs.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported
32GB
Channel Supported
Dual Channel
Expansion Slots
PCI Express 3.0 x16
AMD Ryzen 1st Generation Processors
1 x PCIe 3.0/2.0 x16 (x16 or dual x8)
AMD Ryzen with Radeon Vega Graphics / 7th Generation A-Series/Athlon X4 Processors
1 x PCIe 3.0/2.0 x16 (x8 mode)
PCI Express x1
2 x PCIe 2.0 x1
Storage Devices
SATA 6Gb/s
4 x SATA 6Gb/s port(s), gray
M.2
AMD Ryzen with Radeon Vega Graphics/ Ryzen 1st Generation Processors:
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x4 mode)
AMD 7th Generation A-series/Athlon Processors:
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x2 mode)
SATA RAID
0/1/10
Onboard Video
Onboard Video Chipset
Integrated Graphics in the AMD Ryzen with Radeon Vega Graphics/ 7th Generation A-Series APU
Multi-VGA output support: HDMI/RGB ports
– Supports HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz
– Supports RGB with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 2048MB (for iGPU exclusively)
Onboard Audio
Audio Chipset
Realtek ALC887
Audio Channels
8 Channels
Onboard LAN
LAN Chipset
Realtek RTL8111H
Max LAN Speed
10/100/1000Mbps
Rear Panel Ports
PS/2
1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
Video Ports
1 x D-Sub
HDMI
1 x HDMI
RJ45
1 x RJ45
USB 3.1
4 x USB 3.1 Gen 1 (blue)
USB 1.1/2.0
2 x USB 2.0
Audio Ports
3 Ports
