R8P13-61001 Technical Specifications
HPE 48x Ports 1/10/25GbE SFP28 Network Switch
Manufacturer Part Number: R8P13-61001
Brand Name: HPE
Product Line: Data Center Switch
Product Type: Managed 25GbE Switch
Total Ports: 48
25-Gigabit Ethernet Ports: 48 x SFP28 (supports 1/10/25GbE)
Uplink Ports: 6 x QSFP28 (40/100GbE)
Switching Capacity: 6.4 Tbps
Forwarding Rate: 4,760 Mpps
Layer Support: Layer 2 / Layer 3 / Layer 4
MAC Address Table: 512,000 entries
VLAN Support: Up to 4,094 VLANs (IEEE 802.1Q)
Routing: Static, OSPF, BGP, IS-IS, IPv4/IPv6
Spanning Tree Protocols: STP, RSTP, MSTP
Link Aggregation: IEEE 802.3ad LACP
Flow Control: IEEE 802.3x
Quality of Service (QoS): 8 queues, DSCP, IEEE 802.1p
