SRX-MP-WLAN-US Juniper Networks Wi-Fi Mini-Physical Interface Module
SRX-MP-WLAN-US Overview
The Wi-Fi Mini-Physical Interface Module (Mini-PIM) for branch SRX Series Services Gateways provides a branch-in-a-box solution (which includes an SRX Series device, LTE, and wi-fi) for retail and small office deployments. The Mini-PIM has an embedded enterprise-class wireless system-on-chip (SOC) that supports the 802.11ac Wave 2 wireless standards. The Mini-PIM is backward-compatible with 802.11a, 802.11b, 802.11g, and 802.11n.
$238
SRX-MP-WLAN-US Technical Specifications
Juniper Networks Wi-Fi Mini-Physical Interface Module expansion module
Manufacturer :Netscreen
Brand :Juniper, Juniper Networks
Product Line :Juniper Networks
Model :Wi-Fi Mini-Physical Interface Module
Country Kits :United States
Packaged Quantity :1
Networking
Type :Expansion module
Form Factor :Plug-in module
Connectivity Technology :Wireless
Data Link Protocol :IEEE 802.11a, IEEE 802.11n, IEEE 802.11g, IEEE 802.11ac, IEEE 802.11b
Wi-Fi Bands :2.4 GHz, 5 GHz
Status Indicators :Status
Interface Provided
Interfaces :2 x antenna – RP-SMA, 1 x console – mini-USB Type B
Power Device
Power Consumption Operational :7.12 watt
Dimensions & Weight
Width :3.7 inch
Depth :5.3 inch
Height :0.8 inch
Weight :4.59 ounce
Environmental Parameters
Min Operating Temperature :32 degree Fahrenheit
Max Operating Temperature :104 degree Fahrenheit
Humidity Range Operating :5 – 90% (non-condensing)
