Home›Transceivers›HP Transceiver›XVR-00060-02 HP 40Gbps 40GBase-SR4 Transceiver Module
HP-XVR-00060-02

XVR-00060-02 HP 40Gbps 40GBase-SR4 Transceiver Module

XVR-00060-02 Overview

The HP XVR-00060-02 is a high-speed 40Gbps QSFP+ optical transceiver designed for short-range data center connectivity using multi-mode fiber. Supporting the 40GBase-SR4 standard, it uses parallel optics with four transmit and four receive lanes, each running at 10Gbps, to deliver efficient, low-latency connections over distances of up to 100 meters on OM3 fiber or 150 meters on OM4 fiber. Its MPO connector enables high-density cabling, while the hot-pluggable form factor allows for quick deployment and replacement without network downtime. This module is ideal for high-throughput enterprise environments, top-of-rack switching, and server-to-switch interconnects.

Wishlist
Compare
Availability: In Stock
SKU:XVR-00060-02
Brand:

XVR-00060-02 Technical Specifications

HP 40Gbps 40GBase-SR4 Multi-mode Fiber 100m 850nm MPO Connector QSFP+ Transceiver Module

Manufacturer: HP
Manufacture Part Number: XVR-00060-02
Product Type: QSFP+ Transceiver Module
Data Rate: 40Gbps
Standard: 40GBase-SR4
Fiber Type: Multi-mode Fiber (MMF)
Maximum Distance: Up to 100m (OM3 fiber) / 150m (OM4 fiber)
Wavelength: 850nm
Connector Type: MPO (Multi-fiber Push-On/Pull-off)
Form Factor: QSFP+
Transmission Mode: Parallel optics, 4 lanes at 10Gbps each
Hot-Pluggable: Yes
Power Consumption: Low-power design
Applications: High-speed data center interconnects, aggregation switches, enterprise networks
Compliance: IEEE 802.3ba, QSFP+ MSA standards
