21GXV Dell 960gb Pcie Gen3 X4 Nvme M.2 Solid State Drive SSD
21GXV Overview
The Dell 960GB U.2 Nvme Ssd Ri In Poweredge 14/15/16 Gen 2.5” Tr (Dell part 21GXV) is a 960 GB enterprise‑class solid‑state drive designed primarily for Dell PowerEdge servers and other systems that support PCIe Gen3 ×4 NVMe storage in the M.2 22110 form factor. It’s built with 3D Triple‑Level Cell (TLC) NAND flash memory and optimized for read‑intensive workloads—meaning it’s most efficient in environments where frequent reading of data is more common than heavy writing.
Using the PCIe Gen3 ×4 NVMe interface, this SSD delivers a substantial performance boost over older SATA solutions and earlier hardware, improving boot times, application access, and throughput for server workloads.
21GXV Technical Specifications
Dell 960gb Pcie Gen3 X4 Nvme M.2 Read Intensive 1dwpd Tlc Enterprise Solid State Drive Ssd For DELL Poweredge Server
Manufacturer : DELL
DELL Part Number : 21GXV
Technical Information :
Interface : Pcie Gen3 X4
Storage Capacity : 960gb
Form Factor : M.2 22110
Flash Memory Technology : 3d Tlc Nand
Endurance Type: Read Intensive
Ssd Endurance Dwpd: 1 Dwpd
Performance :
Sequential Read (max) : 2700 Mb/s
Sequential Write (max) : 1730 Mb/s
Random Read (max) : 450k Iops
Random Write (max) : 50k Iops
Power Consumption :
Active Read: Up To 8.25w
Active Write: Up To 8.25w
Active Idle: Up To 5.0w
Physical Features :
Width: 22 ±0.13mm
Length: 110 ±0.13mm
Thickness: Max 4.23mm
