2274200-R Adaptec 7805 PCI-E 3.0 x8 1GB SAS-SATA 6GBPS
2274200-R Overview
The Adaptec 2274200-R 7805 RAID controller supports RAID levels 0, 1, 1E, 5, 6, 10, 50, and 60. This means you can configure your hard drives in a variety of ways depending on your needs. The card also supports SAS and SATA hard drives with transfer speeds of up to 6Gbps.
The Adaptec 7805 also features a built-in DDR3 cache memory of up to 1GB. This allows for faster data access and transfer speeds. The card also supports Adaptec’s maxCache 3.0 caching software, which provides even faster performance by caching frequently accessed data in the card’s cache memory.
$30
2274200-R Technical Specifications
Adaptec 7805 Peripheral Component Interconnect Express (PCI-E) 3.0 x8 1GB SAS-SATA 6GBPS RAID Controller
Manufacturer: Adaptec
Part Number or SKU# 2274200-R
Product Type : Controller
Product Name : SAS-SATA
Technical Specifications
Controller Interfaces Type: Serial Attached Scsi (sas)
Host Interface: Pci Express 3.0 X8
Data Transfer Rate: 768 Mbps
Raid Supported: Yes
Raid Levels: 0 . 1 . 1e . 5 . 6 . 10 . 50 . 60 .
Drive Supported: 256 X Physical
Platform Supported: Pc
Standard Memory: 1gb
Ports: 2 X Sff-8643 6gb/s Sas – Serial Attached Scsi (sas) Internal
Form Factor: Low-profile Plug-in Card
