Refurbished 257919-001 Technical Specifications
HP Proliant Ml370 G3 1x Intel Xeon 2.4GHz 512MB RAM 48x Cd-ROM FDD Gigabit Ethernet ILO Tower Server.
General information :
Manufacturer: hewlett packard
Manufacturer part number: 257919-001
Product name: Proliant ml370 G3 tower server
Processor & chipset :
Processor type: intel xeon 2.4 GHz
Installed qty: 1
Max supported qty: 2
Upgradability: upgradable
Chipset type: serverworks grand champion le
Data bus speed: 400 MHz
Cache memory :
Cache memory type: l2 cache advanced transfer cache
Installed size: 512 kb
Cache per processor: 512 kb
Memory :
Installed size: 512 mb
Max supported qty: 12 gb
Technology: ddr sdram – ecc
Memory speed: 266 mhz
Memory specification compliance: pc2100
Form factor: dimm 184-pin
Storage & storage controller :
Hard drive: none
Floppy drive: 3.5in in 1.44 mb floppy
Optical storage: 48x cd-rom – ide
Storage controller type(1st): 1 x scsi – integrated
Controller interface type: ultra160 scsi
Channel qty: 2
Storage controller type(2nd): 1 x ide – integrated
Controller interface type: eide/atapi
Graphics controller :
Graphics controller type: pci-integrated
Graphics processor: ati rage xl
Video memory: sdram
Installed size: 8 mb/8 mb (max)
Networking :
Networking: network adapter – pci-x – integrated
Data link protocol: ethernet, fast ethernet, gigabit ethernet
Features: full duplex capability, wake on lan (wol)
Compliant standards: ieee 802.3, ieee 802.3u
Expansion & connectivity :
Expansion bays total (free):
1 ( 0 ) x front accessible-3.5in x 1/3h
3 ( 2 ) x front accessible-5.25in x 1/2h
6 ( 6 ) x hot-swap-3.5in x 1/3h
Expansion slots total (free):
2 ( 1 ) x processor-socket 603
6 ( 4 ) x memory-dimm 184-pin
6 ( 6 ) x pci-x/100 mhz
Interfaces & ports :
1 x parallel-ieee 1284 (epp/ecp)-25 pin d-sub (db-25)
2 x serial-rs-232-9 pin d-sub (db-9)
1 x mouse-generic-6 pin mini-din (ps/2 style)
1 x keyboard-generic-6 pin mini-din (ps/2 style)
1 x display/video-vga-15 pin hd d-sub (hd-15)
2 x usb-4 pin usb type a
1 x network-ethernet 10base-t/100base-tx-rj-45
1 x management
1 x storage-ultra160 scsi-68 pin vhdci (mini-centronics)
Power description :
Power device type: power supply – hot-plug
Power redundancy: optional
Power redundancy scheme: 1+1 (with optional power supply)
Installed qty: 1
Max supported qty: 2
Voltage required: ac 110/220 v ± 18% ( 50/60 hz )
Power provided: 500 watt
