Refurbished 348447-B21 Technical Specifications
HP Proliant Dl760 G1 4p Xeon Mp 2.2GHz 2GB Ram Ultra160 SCSI 24x Cd-ROM FDD Gigabit Ethernet Ilo 4u Rack Server.
GENERAL INFORMATION:
Manufacturer: Hewlett-Packard
Manufacturer Part Number: 348447-B21
Product Name: Proliant Dl740 G1 4u Rack mount Server
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon Mp 2.2 Ghz
Installed Processor Qty: 4
Max Supported Qty: 8
Upgradability: Upgradable
Chipset Type: Hp F8
CACHE MEMORY:
Type: L3 Cache
Installed Size: 8 Mb
Cache Per Processor: 2 Mb
MEMORY:
Installed Ram Size: 2 Gb / 64 Gb (Max)
Technology: Sdram – Ecc
Memory Speed: 133 Mhz
STORAGE:
Floppy Drive: 3.5 1.44 Mb Floppy
Hard Drive: None.
Internal Storage : 587.2 Gb Maximum (With Optional Hard Drives)
Optical Storage Type: Dvd-Rom – Id
Read Speed: 24x (Cd) / 8x (Dvd)
STORAGE CONTROLLERS:
Storage Controller Type: 1 X Raid – Integrated
Controller Interface Type: Ultra160 Scsi
Storage Controller Name: Smart Array 5i Controller
Channel Qty: 2
Raid Level: Raid 0, Raid 1, Raid 5, Raid 10
Buffer Size: 32 Mb
DISPLAY & GRAPHICS:
Graphics Controller Type: Integrated
Graphics Processor: Ati Rage Xl
Video Memory: 8 Mb Sdram
NETWORK & COMMUNICATION:
Two Nc7781 Pci-X Gigabit Nics (Embedded)
Networking: Network Adapter – Pci-X / 66 Mhz – Integrated
Data Link Protocol: Ethernet, Fast Ethernet, Gigabit Ethernet
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.3ab Ds
POWER DESCRIPTION:
Device Type: Power Supply – Hot-Plug
Power Redundancy: Yes
Power Redundancy Scheme: 1+1
Installed Qty: 2
Max Supported Qty: 2
Voltage Required: Ac 120/230 V ( 50/60 Hz )
