405-AAJB Technical Specifications
Dell PERC H730P 2GB NV Cache SAS 12Gbps PCI Express 3.0 x8 RAID Controller Card
Category Dell Controller
Sub-Category RAID Controller
Generation PCI-Express
Part Number 405-AAJB
Products ID 725695
Device Type Storage Controller (RAID) Plug-In Card
Bus Type PCIe 3.0 x8
Interface 12Gb/s SAS / 6Gb/s SATA
Data Transfer Rate 1.2GB/s
Buffer Size 2GB
Channel Qty 8
Max Storage Device Qty 255
RAID Level RAID 0 1 5 6 10 50 60
Dimensons D x H 16.76cm x 6.44cm
Max Operating Temperature 55°℃
Form Factor Mini SAS
