405-AAOD Technical Specifications
Dell PERC H740P RAID Controller 8GB NV Cache
Device Type : Storage Controller (raid) – Plug-in Card
Host Bus : Pcie 3.1 X8
Interface : Sata 6gb/s / Sas 12gb/s
Data Transfer Rate : 12 Gbit/s
Supported Devices : Hard Drive, Disk Array (raid), Solid State Drive
Max Storage Devices Qty : 32
Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Processor : Lsi Lsisas3508
Max Operating Temperature : 140 °f
Designed For : Dell Emc Poweredge R440, R540, R740, R740xd, R940, T440, T640
