Refurbished 463-3714 Technical Specifications
Dell Poweredge T630 Gen 13th 1X Xeon 6 Core E5-2609-V3/1.9GHz, 8GB DDR4 SDRAM, 1X 300GB SAS 6GB/S HDD, 2X Gigabit Ethernet, 1X 495W PS, 5U Tower Server.
GENERAL INFORMATION :
Manufacturer : Dell
Manufacturer Part Number : 463-3714
Product Name : Poweredge T630 Gen 13th 5u Tower Server
PROCESSOR & CHIPSET :
CPU: Intel Xeon E5-2609V3 / 1.9GHz
Number Of Cores : Hexa-Core (6-Core)
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Chipset Type : Intel C610
Cache Memory : L3 Cache
Cache Per Processor : 15 MB
MEMORY :
Installed Size : 8 GB / 768 GB (MAX)
Technology : DDR4 SDRAM – ECC
Memory Speed : 1600 MHz
Memory Specification Compliance : PC4-17000
Form Factor : DIMM 288-pin
Memory Slots: 24 x DDR4 RAM Slots
Configuration Features : 1 X 8 GB
Ram Supported : 768 GB – Load-Reduced – ECC 384 GB – Registered – ECC
STORAGE & STORAGE CONTROLLER :
Hard Drive Capacity : 1X 300GB Hot-Swap
Interface Type : SAS 6GB/S
Spindle Speed : 10000 RPM
Optical Storage Type : DVD-ROM – SATA
Storage Controller Type : 1 X RAID
Storage Controller Name : Dell PERC H330
Raid Level : RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
NETWORK & COMMUNICATION :
Networking Type : Integrate
Ethernet Ports : 2 X Gigabit Ethernet
Ethernet Controller : Broadcom BCM5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Integrated Dell Remote Access Controller 8 Express (IDRAC8)
EXPANSIONS & CONNECTIVITY :
Expansion bays total (free) :
16 (Total) / 15 (Free) X Hot Swap 2.5inch Sas Hdd
EXPANSION SLOTS TOTAL (FREE) :
2 (TOTAL) / 1 (FREE) X CPU
24 (Total) / 23 (Free) X Dimm 288-Pin
2 Pcie 3.0 X16 – Full-Length, Full-Height
1 Pcie 2.0 X4 – Full-Length, Full-Height
1 Pcie 3.0 X8 – Half-Length, Full-Height
INTERFACES & PORTS :
4 X USB 2.0
3 X USB 3.0 ( 1 Front, 2 Rear )
2 X LAN (Gigabit Ethernet)
2 X VGA ( 1 Front, 1 Rear )
1 X Serial
1 X Management (Nic)
POWER DEVICE :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
Power Provided : 495 WATT
