463-3992 Technical Specifications
Dell Poweredge R630 13TH GEN 1X Intel XEON 12 CORE E5-2690V3/ 2.6GHz 16GB DDR4 SDRAM1X 300 GB HDD Dell Perc H730P With 2 GB BCM5720 1X 750W PS 1U Mountable Server.
GENERAL INFORMATION :
Manufacturer : dell
Manufacturer part number : 463-3992
Product name: poweredge r630 13th gen – 1u rack mountable server
PROCESSOR & CHIPSET :
Cpu : intel xeon e5-2690v3 / 2.6 ghz
Max turbo speed : 3.5 ghz
Number of cores : 12-core
Cpu qty : 1
Max cpu qty : 2
Cpu upgradability : upgradable
Processor main features : hyper-threading technology, intel turbo boost technology 2
Cpu socket : lga2011-v3 socket
Chipset type : intel c610
CACHE MEMORY :
Cache memory type : smart cache
Installed size : 30 mb
Cache per processor : 30 mb
MEMORY :
Installed size : 16 gb / 768 gb (max)
Technology : ddr4 sdram – ecc
Memory speed : 2133 mhz
Memory specification compliance : pc4-17000
Form factor : dimm 288-pin
Memory Slots: 24 x DDR4 RAM Slots
Features : registered, dual rank
Configuration features : 1 x 16 gb
Ram supported : 768 gb – load-reduced – ecc ¦ 384 gb – registered – ec
STORAGE:
Hard drive :
Type : hdd – hot swap
Capacity : 1 x 300 gb
Interface type : sas 6gb/s
Spindle speed : 10000 rpm
optical drive : dvd-rom – sata
STORAGE CONTROLLERS :
Controller type : 1 x raid
Storage controller name : dell perc h730p
Raid level : raid 0, raid 1, raid 5, raid 10, raid 50, raid 60
Buffer size : 2 gb
