Refurbished 463-5894 Technical Specifications
Dell Poweredge R730 1X Xeon 6 Core E5-2620-V3/2.4GHZ, 8GB DDR4 SDRAM, 1X 300GB HDD, Gigabit Ethernet, 750W PS, 2U Rack Mountable Server.
GENERAL INFORMATION :
Manufacturer : Dell
Manufacturer Part Number : 463-5894
Product Name : Poweredge R730 2u Rack Mountable Server
PROCESSOR & CHIPSET :
CPU: Intel Xeon E5-2620V3 / 2.4GHz
Max Turbo Speed : 3.2 GHz
Number Of Cores : 6-CORE
Installed Cpu Qty : 1
Max Cpu Qty : 2
Processor Main Features : Intel Turbo Boost Technology 2
Cpu Socket : LGA2011-V3 SOCKET
Chipset Type : Intel C610
CACHE MEMORY :
Installed Size : L3 CACHE – 15 MB
Cache Per Processor : 15 MB
MEMORY :
Installed Size : 8 GB / 768 GB (MAX)
Technology : DDR4 SDRAM – ECC
Memory Speed : 2133 MHZ
Memory Specification Compliance : PC4-17000
Form Factor : DIMM 288-pin
Memory Sots :24 x DDR4 RAM Slots
Features : Registered, Dual Rank
Configuration Features : 1 X 8 GB
Ram Supported : 768 GB – Load-Reduced – ECC 384 GB – Registered – ECC
STORAGE & STORAGE CONTROLLER :
Hard Drive Type : HDD – Hot-Swap
Capacity : 1 X 300 GB
Interface Type : SAS 6GB/S
Spindle Speed : 10000 RPM
Storage Controller Type : 1 X SAS-3
Controller Interface Type : SAS 12GB/S
Storage Controller Name : Dell PERC H730
Raid Level : RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
Buffer Size : 1 GB
NETWORK & COMMUNICATION :
Networking Type : Integrated
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : Broadcom Bcm5720
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller : Integrated Dell Remote Access Controller 8 Express (IDRAC8)
EXPANSIONS & CONNECTIVITY :
Expansion bays total (free) : 8 (TOTAL) / 7 (FREE) X HOT-SWAP 2.5INCH
EXPANSION SLOTS TOTAL (FREE) :
2 (TOTAL) / 1 (FREE) X CPU
24 (TOTAL) / 23 (FREE) X DIMM 288-PIN
3 PCIE 3.0 X16 – LOW-PROFILE ( X8 MODE )
2 PCIE 3.0 X16 – FULL-LENGTH, FULL-HEIGHT
1 PCIE 3.0 X16 – FULL-LENGTH, FULL-HEIGHT ( X8 MODE )
INTERFACES & PORTS :
2 X USB 3.0
2 X VGA ( 1 FRONT, 1 REAR )
1 X USB 2.0
1 X SERIAL
4 X LAN (GIGABIT ETHERNET)
POWER DEVICE :
Device Type : Power Supply – Hot Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1
Installed Qty : 1
Max Supported Qty : 2
Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
Power Provided : 750 WATT
