463-7034 Dell Poweredge R430 13th Gen 1x Intel Xeon 6-Core
463-7034 Overview
Dell PowerEdge R430 – Server – rack-mountable – 1U – 2-way – 1 x Xeon E5-2603V3 / 1.6 GHz – RAM 8 GB – SAS – hot-swap 3.5″ – HDD 1 TB – DVD-Writer – Matrox G200 – GigE – no OS – monitor: noneDelivering peak 2-socket performance to space-constrained data centers, the PowerEdge R430 is a short-depth entry rack server. It is an excellent fit for a wide range of workloads, including high-performance computing (HPC), web serving, infrastructure scale-out, surveillance and site security. The R430 is also highly attractive as a dedicated backup or development server.
$2,745
463-7034 Technical Specifications
Dell Poweredge R430 13th Gen 1x Intel Xeon 6-Core E5-2603V3/ 1.6GHz, 8GB DDR4 SDRAM RAM, 1X 1 TB HDD, Rack Mountable Server.
GENERAL INFORMATION :
Manufacturer : Dell
Manufacturer Part Number : 463-7034
Product Name: Poweredge R430 13th Gen – 1u Rack Mount Server
PROCESSOR & CHIPSET :
CPU : Intel Xeon E5-2603V3 / 1.6 GHz
Number Of Cores : 6-Core
Cpu Qty : 1
Max Cpu Qty : 2
Cpu Upgradability : Upgradable
Chipset Type : Intel C610
CACHE MEMORY :
Cache Memory Type : Smart Cache
Installed Size : 15 MB
Cache Per Processor : 15 MB
MEMORY :
Installed Size : 8 GB / 384 GB (MAX)
Technology : DDR4 SDRAM – ECC
Memory Speed : 2133 MHZ
Form Factor : DIMM 288-PIN
Memory Slots: 12 x DDR4 RAM Slots
Features : Registered
Configuration Features : 1 X 8 GB
STORAGE:
Hard drive :
Type : HDD – Hot-Swap
Capacity : 1 X 1 TB
Interface Type : SATA 6GB/S
Spindle Speed : 7200 RPM
Optical Drive : DVD-ROM – SATA
STORAGE CONTROLLERS:
Type : 1 X RAID
Controller Interface Type : SATA 6GB/S / SAS 6GB/S
Storage Controller Name : Dell Perc H330
Raid Level : Raid 0, RAID 1, RAID 5, RAID 10, RAID 50
DISPLAY & GRAPHICS CONTROLLERS :
Type : Integrated
Graphics Processor : Matrox G200
Video Memory : 16 MB
Video Interfaces : VGA
NETWORK & COMMUNICATION:
Ethernet Ports : 4 X Gigabit Ethernet
Data Link Protocol : Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol : Ipmi 2.0
POWER DESCRIPTION :
Device Type : Power Supply – Hot-Plug
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (With Optional Power Supply)
Installed Qty : 1
Max Supported Qty : 2
Power Provided : 550 WATT
EXPANSION/ CONNECTIVITY :
Expansion bays total (free) :
1 (Total) / 0 (Free) X External 5.25 Ultra Slim
4 (Total) / 3 (Free) X Hot-Swap 3.5
EXPANSION SLOTS TOTAL (FREE) :
2 (TOTAL) / 1 (FREE) X CPU
12 (TOTAL) / 11 (FREE) X DIMM 240-PIN
2 PCIE X16 – HALF-LENGTH, LOW-PROFILE
2 PCIE X8 – FULL-LENGTH, FULL-HEIGHT
INTERFACES & PORTS :
2 X VGA ( 1 FRONT, 1 REAR )
4 X LAN (GIGABIT ETHERNET)
SERIAL
2 X USB 2.0 ( 2 FRONT, 1 REAR )
1 X USB 3.0 ¦ 1 X MANAGEMENT (NIC)
