481548-002 Technical Specifications
HP Dc Director Board 8GB 48-Ports Blade Option
Manufacturer: HP
Manufacturer Part Number: 481548-002
Port Count: 48 Fibre Channel ports
Port Speed: 8Gbps per port (auto-negotiates to 2/4/8 Gbps)
Port Type: SFP-based Fibre Channel interfaces
Form Factor: Blade option for HP StorageWorks SAN Director chassis
Application: Expands port density in HP StorageWorks Director-class switches
Switching Architecture: High-performance, non-blocking fabric design
Aggregate Bandwidth: Up to 768 Gbps (full duplex across all ports)
Supported Standards: FC-SW, FC-AL, FC-FS, FC-GS
Scalability: Enables large-scale SAN fabrics with thousands of nodes
Redundancy Support: Works with redundant supervisor boards in chassis
Hot-Swap Capable: Blade can be replaced without downtime
Management Interfaces: CLI, Web GUI, SNMP, HP StorageWorks management tools
Fabric Services: Name server, RSCN, zoning, fabric login
