4Y37A09735 Technical Specifications
Lenovo ThinkSystem 940-16i Storage Controller (RAID) SATA / SAS 12Gb/s PCIe 4.0 x8
Brand : Lenovo
Manufacturer Part Number : 4Y37A09735
Interface SATA / SAS 12Gb/s
Data Transfer Rate 12 Gbit/s
Buffer Size 8 GB
Supported Devices Hard drive, disk array (RAID), solid state drive
Max Storage Devices Qty 16
RAID Level RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60
Processor Broadcom SAS3916
General
Device Type Storage controller (RAID) – plug-in card
Host Bus PCIe 4.0 x8
Expansion / Connectivity
Interfaces 2 x SAS 12Gb/s – Slim SAS (SFF-8654) (internal)
