670853-S01 HP ProLiant DL380p G8 2U Rack Server 2 x Intel

670853-S01 Technical Specifications

HP ProLiant DL380p G8 2U Rack Server 2 x Intel Xeon E5-2660 2.2GHz.

GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 670853-S01
Product Name: Proliant Dl380p Gen8 – 2-Way 2u Rack Mount  (S-Buy)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2660 / 2.2 Ghz
Multi-Core Technology: Octa-Core (8 Core)
64 Bit Computing: Yes
Installed Qty: 2
Max Supported Qty: 2
Upgradability: Upgradable
Chipset Model: Intel C600
CACHE MEMORY:
Type: L3 Cache
Installed Size: 40 Mb
Cache Per Processor: 20 Mb
MEMORY:
Installed Size: 32 Gb/384 Gb (Max)
Technology: Ddr3 Sdram
Form Factor: Dimm 240-Pin
Number Of Total Memory Slots: 24 Ddr3 Slots
Features: Registered, Dual Rank, Quad Channel Memory Architecture, Hp Smartmemory
Configuration Features: 4 X 8 Gb
RAM SUPPORTED:
Pc3-12800 – 384 Gb – Registered
Pc3-10600 – 768 Gb – Load-Reduced
Pc3-12800 – 128 Gb – Unbuffered – Advanced Ecc
Pc3-10600 – 384 Gb – Hypercloud
STORAGE & STORAGE CONTROLLERS:
Hard Drive: None
Optical Drive Type: None
Type : Card Reader
Supported Flash Memory Cards : Sd Memory Card
Storage Controller Type: 1 X Raid – Plug-In Card – Pci Express 3.0 X8
Storage Controller Name: Hp Smart Array P420i With 1gb Fbwc
Raid Level: Raid 0 Raid 1 Raid 5 Raid 10 Raid 50
Buffer Size: 1 Gb
DISPLAY & GRAPHICS:
Graphics Type: Integrated
Graphics Controller Model: Matrox G200
Video Interfaces : Vga
NETWORK & COMMUNICATION:
Interface (Bus) Type : Pci Express X4
Ethernet Ports: 4 X Gigabit Ethernet
Ethernet Controller(S): Hp 331flr
Data Link Protocol: Ethernet Fast – Ethernet – Gigabit Ethernet
Remote Management Controller: Integrated Lights-Out 4
Features: Wake On Lan (Wol), Pxe Support
Compliant Standards: Ieee 802.3, Ieee 802.3u, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3ad (Lacp)
