670854-S01 Technical Specifications
HP ProLiant DL380p G8 2U Rack Server 2 x Intel Xeon E5-2640 2.5GHz.
GENERAL INFORMATION:
Manufacturer: Hewlett Packard
Manufacturer Part Number: 670854-S01
Product Name: Proliant Dl380p Gen8 – 2u Rack Mount (Smart Buy)
PROCESSOR & CHIPSET:
Processor Type: Intel Xeon E5-2640 / 2.5 Ghz
Compatible Slots: Lga2011 Socket
Multi-Core Technology: Hexa-Core (6 Core)
Quickpath Interconnect: 7.20 Gt/S
64 Bit Computing: Yes
Installed Qty: 2
Max Supported Qty: 2
Upgradability: Upgradable
Processor Main Features: Hyper Threading Technology
Chipset Model: Intel C600
CACHE MEMORY:
Type: L3 Cache
Installed Size: 30 Mb
Cache Per Processor: 15 Mb
MEMORY:
Installed Size: 16 Gb / 384 Gb (Max)
Technology: Ddr3 Sdram
Memory Speed: 1333 Mhz
Memory Specifications Compliance: Pc3-10600
Form Factor: Dimm 240-Pin
Number Of Total Memory Slots: 24 Ddr3 Slots
Configuration Features: 2 X 8 Gb
Features: Registered, Dual Rank, Quad Channel Memory Architecture, Hp Smartmemory
RAM SUPPORTED:
Pc3-12800 – 384 Gb – Registered
Pc3-10600 – 768 Gb – Load-Reduced
Pc3-12800 – 128 Gb – Unbuffered – Advanced Ecc
Pc3-10600 – 384 Gb – Hypercloud
STORAGE:
Hard Drive : None
Optical Drive : None
STORAGE CONTROLLERS:
Type : 1 X Raid – Integrated – Pci Express 3.0 X8
Controller Interface Type : Sata 6gb/S / Sas 6gb/S
Storage Controller Name : Smart Array P420i With 1gb Fbwc
Raid Level : Raid 0, Raid 1, Raid 5, Raid 10, Raid 50
Buffer Size : 1 Gb
DISPLAY & GRAPHICS:
Graphics Type: Integrated
Graphics Controller Model: Matrox G200
Video Interfaces : Vga
NETWORK & COMMUNICATION:
Networking Type : Plug-In Card
Interface (Bus) Type : Pci Express X4
