679114-B21 HP Proliant Bl660c G8 4 X Intel 8 Core Xeon E5 4650

679114-B21 Technical Specifications

HP Proliant Bl660c G8 4 X Intel 8 Core Xeon E5 4650 2.7 GHz 128 GB DDR3 SDRAM 0 HDD RAID 0 1 HP Smart Array.

GENERAL INFORMATION :
Manufacturer : Hewlett packard
Manufacturer part number : 679114-B21
Product name : proliant bl660c g8 – 4-way blade server (performance model)
PROCESSOR & CHIPSET :
Processor type : intel xeon e5-4650 / 2.7 ghz
Number of cores : 8 core
64-bit computing : yes
Installed qty : 4
Max supported qty : 4
Upgradability : upgradable
Chipset Type : Intel C600
CACHE MEMORY :
Cache memory type : l3 cache
Installed size : 80 mb
Cache per processor : 20 mb
MEMORY :
Installed size : 128 gb
Maximum size : 1.0 tb
Memory speed : 1600 mhz
Memory specification compliance : pc3-12800
Configuration features : 16 x 8 gb
Technology : ddr3 sdram
Form factor : dimm 240-pin
RAM SUPPORTED :
Pc3-12800 – 512 gb – registered
Pc3-10600 – 1024 gb – load-reduced
Storage & storage controller :
Hard drive : none
Card reader type : card reader
Supported flash memory cards : microsd, microsdhc
Storage controller type : 1 x sas-2 – pci express x4
Controller interface type : sas 6gb/s
Storage controller name : smart array p220i with 512mb fbwc
Raid level : raid 0, raid 1
Display & graphics controllers :
Graphics controller type : integrated
Graphics processor : matrox g200
Network & communication :
Networking : plug-in card
Interface (bus) type : flexiblelom
Ethernet ports : 4 x 10 gigabit ethernet
Ethernet controller(s) : 2 x hp 554flb
Data link protocol : gigabit ethernet, 10 gigabit ethernet
Remote management protocol : snmp, ipmi 2.0, smash clp
Remote management controller : integrated lights-out 4
Compliant standards : ieee 802.1q, ieee 802.1p, ieee 802.3x, ieee 802.3ad (lacp), ieee 802.3ae, ieee 802.3ap, ieee 802.1qau
