70G00023US Technical Specifications
Lenovo N4610 E5-2603V3 8GB 1X2TBSAS, 1X500SATA 3
General Information
Product Name N4610 E5-2603V3 8GB 1X2TBSAS, 1X500SATA 3
Manufacturer Part Number 70G00023US
Product Model N4610
Product Type NAS Storage System
Interfaces/Ports
Total Number of USB Ports 4
Number of USB 2.0 Ports 2
Number of USB 3.0 Ports 2
Network (RJ-45) Yes
Controllers
Controller Type Serial ATA/300
RAID Supported Yes
RAID Levels 0, 1, 5, 6, 10, 50, 60
I/O Expansions
Number of Total Expansion Bays 14
Number of 3.5″ Bays 12
Number of 2.5″ Bays 2
Number of Total Expansion Slots 9
Memory
Standard Memory 8 GB
Network & Communication
Ethernet Technology Gigabit Ethernet
Storage
Number of Hard Drives Installed 6
Total Hard Drive Capacity Installed 9 TB
Processor & Chipset
Number of Processors Installed 1
Processor Manufacturer Intel
Processor Type Xeon
Processor Model E5-2603 v3
Processor Core Hexa-core (6 Core)
Processor Speed 1.60 GHz
Software
Operating System Windows Storage Server 2012 R2
Physical Characteristics
Height 3.4″
Width 19″
Depth 30.8″
Form Factor Rack-mountable
Rack Height 2U
