740-035329 Juniper 100Gb/s 100GBASE-SR10 MMF MPO CFP Transceivers
740-035329 Overview
The Juniper 740-035329 is a high-speed 100Gbps CFP optical transceiver designed for short-reach data center and high-performance networking applications. Supporting the 100GBASE-SR10 standard, it operates over multi-mode fiber (MMF) and delivers reliable connections up to 100 meters on OM3 fiber and 150 meters on OM4 fiber.This module uses an MPO-24 connector for parallel optics transmission across 10 lanes of 10Gbps each, aggregating to 100Gbps full-duplex bandwidth. Fully compliant with IEEE 802.3ba and CFP MSA specifications, it ensures seamless interoperability across Juniper switches, routers, and compatible platforms.Engineered for low-latency and high-throughput environments, the 740-035329 is well-suited for cloud-scale data centers, HPC clusters, enterprise backbones, and high-density interconnects.
740-035329 Technical Specifications
Juniper 100Gb/s 100GBASE-SR10 MMF MPO CFP Transceivers
Manufacturer Part Number: 740-035329
Brand Name: Juniper Networks
Product Type: CFP Transceiver Module
Data Rate: 100Gbps
Transceiver Type: 100GBase-SR10
Media Type Supported: Multi-Mode Fiber (MMF)
Wavelength: 850nm
Connector Type: MPO-24
Maximum Reach: Up to 100m (OM3) / 150m (OM4)
Form Factor: CFP
Hot Swappable: Yes
Digital Diagnostics Monitoring (DOM): Supported
Fiber Strand Count: 20 (10 transmit, 10 receive)
Compatibility: Juniper 100GbE switches and routers
Application: High-speed data center and enterprise backbone connectivity
Standards Compliance: IEEE 802.3ba 100GBASE-SR10, CFP MSA
Backward Compatibility: Not applicable (designed for 100GbE)
Operating Temperature: 0°C to 70°C
Power Consumption: Optimized for energy-efficient operation
Installation: Plug-and-play module
