Refurbished 793309-S01 HP Proliant Dl580 Gen9 Server

Refurbished 793309-S01 Technical Specifications

HP Proliant Dl580 G9 2x Intel Xeon E7 8880v3/2.3ghz 18 Core, 128GB Ddr4 Sdram Smart Array P830i With, 2GB Fbwc, 4x Gigabit Ethernet, 2x 1200w Hot Plug Power Supplies, 4u Rack Server.

General information :
Manufacturer : hewlett packard
Manufacturer part number : 793309-s01
Product name : proliant dl580 g9 – 4u rack mount  server
Processor & chipset :
Cpu : intel xeon e7-8880v3/2.3ghz
Max turbo speed : 2.3 ghz
Number of cores : 18-core
Cpu qty : 2
Max cpu qty : 4
Cpu Upgradability : Upgradable
Processor Main Features : Intel Turbo Boost Technology 2
Chipset Type : Intel C602j
Cache Memory :
Cache Memory Type : Smart Cache
Installed Size : 90 MB
Cache Per Processor : 45 MB
Memory :
Installed Size : 128 GB / 6 Tb (Max)
Technology : Ddr4 Sdram
Memory Speed : 1866 Mhz
Form Factor : Dimm 288-Pin
Memory Slots: 96 x DDR4 RAM Slots
Features : Registered, Online Spare Memory, Quad Channel Memory Architecture, HP Smartmemory
Configuration Features : 16 X 8 GB
Storage:
hard Drive : None
Storage Controllers:
Type : 1 x Raid – Pcie 2.0 X4
Controller Interface Type : Sata 6GB/S / Sas 12GB/S
Storage Controller Name : Smart Array P830i With 2GB Fbwc
Channel Qty : 8
Raid Level : Raid 0, Raid 1, Raid 5, Raid 6, Raid 10, Raid 50, Raid 60
Buffer Size : 2 GB
Graphics Controller :
Graphics Processor : Matrox G200
Video Interfaces : Vga
Network & Communication:
Interface (Bus) Type : Pci Express 2.0×4
Ethernet Ports : 4 X Gigabit Ethernet
Ethernet Controller : HP 331flr
Data Link Protocol : Gigabit Ethernet
Remote Management Controller : Integrated Lights-Out 4
Features : Wake On Lan (Wol), Acpi Support, Pxe Support
Compliant Standards : Ieee 802.3, Ieee 802.3x, Ieee 802.3ad (Lacp), Ieee 802.3ae, Ieee 802.1ax, Ieee 802.1qbb, Ieee 802.1qaz, Ieee 802.1qau, Ieee 802.1qbg, Ieee 802.2x
Power Description :
Device Type : Power Supply – Hot Plug
Power Redundancy : Yes
Power Redundancy Scheme : 1+1
Installed Qty : 2
Max Supported Qty : 4
Nominal Voltage : Ac 120/230 V ( 50/60 Hz )
Power Provided : 1200 Watt
Expansion/Connectivity :
Expansion Bays Total (Free) :
10 (total) / 10 (Free) X Hot-Swap 2.5 Sff
Expansion Slots Total (Free) :
96 (Total) / 80 (Free) X Dimm 240-Pin
4 (Total) / 2 (Free) X Cpu
5 (Total) / 5 (Free) X Pcie 3.0 X16 – Full-Length, Full-Height
4 (Total) / 4 (Free) X Pcie 3.0 X16 – Half-Length, Full-Height ( X8 Mode )
1 (Total) / 0 (Free) X Flexiblelom
1 (Total) / 1 (Free) X Microsd Card
Interfaces & Ports :
1 X Serial
2 X Vga ( 1 Front, 1 Rear )
1 X Hp Ilo
8 X Usb 2.0 ( 2 Front, 4 Rear, 2 Internal )
2 X Lan (10gigabit Ethernet)
Dimensions & Weight :
Depth : 29 Inch
Width : 17.5 Inch
Height : 6.9 Inch
Weight : 70.94 Lbs
