7Y51A04LNA Lenovo ThinkSystem SR250 – rack-mountable

7Y51A04LNA Technical Specifications

Lenovo ThinkSystem SR250 – rack-mountable

Header
Manufacturer :System X Server options
Brand :Lenovo
Product Line :Lenovo ThinkSystem SR250
Model :7Y51
Country Kits :North America
Packaged Quantity :1
System
Type :Server
Hard Drive Capacity :960 GB
Embedded Security :Trusted Platform Module (TPM 1.2 and TPM 2.0)
Chassis
Form Factor :Rack-mountable
Manufacturer Form Factor :Rack-mountable
Hot-Swap Bays Qty :4
Built-in Devices :LED panel
Processor
Type :Xeon
Number of Cores :Quad-Core
Processor Number :E-2174G
Installed Qty :1
Max Supported Qty :1
Server Scalability :1-way
Manufacturer :Intel
Clock Speed :3.8 GHZ
Max Turbo Speed :4.7 GHZ
Processor Main Features :Intel Virtualization Technology, Hyper-Threading Technology
Mainboard
Chipset Type :Intel C246
Cache Memory
Per Processor Size :8 megabyte
Installed Size :8 megabyte
RAM
Form Factor :DIMM 288-pin
Technology :DDR4 SDRAM
Installed Size :16 GB
Max Supported Size :64 GB
Configuration Features :1 x 16 GB
Data Integrity Check :ECC
Slots Qty :4
Empty Slots :3
Memory Speed :2666 megahertz
Rated Memory Speed :2666 megahertz
Features :Unbuffered
Storage Controller
Type :RAID
Bus Type :PCI Express 3.0 x8
Interface Type :Serial ATA-600 / SAS 3.0
Storage Controller Name :ThinkSystem RAID 530-8i
Channel Qty :8
Installed Qty :1
RAID Level :JBOD, RAID 5, RAID 10, RAID 50, RAID 0, RAID 1
Hard Drive
Type :SSD
SSD Form Factor :2.5″
Manufacturer :Intel
Removable :Hot-swap
Interface Class :Serial ATA
Interface Type :Serial ATA-600
Installed Qty :2
Capacity :480 GB
Hard Drive (2nd)
Type :None
Hard Drive (3rd)
Type :None
Hard Drive (4th)
Type :None
Optical Storage
Drive Type :No optical drive
Type :None
Optical Storage (2nd)
Drive Type :No optical drive
Type :None
Storage Removable
Type :None
Display
Type :None.
Video Output
Graphics Processor :Matrox G200
Graphics Processor Series :Matrox G200
Video Interfaces :VGA
Video Memory
Installed Size :16 megabyte
Audio Input
Type :None
Printer
Type :None
Networking
Ethernet Controller(s) :Broadcom BCM5720
Remote Management Controller :XClarity Controller (XCC) Enterprise
Data Link Protocol :Fast Ethernet, Gigabit Ethernet, Ethernet
Ethernet Ports :2 x Gigabit Ethernet
Features :PXE support, Teaming support
