872726-B21 HPE 841QSFP28 Network Adapter PCIe 3.0 x16 100Gb Ethernet
872726-B21 Overview
The HPE InfiniBand adapters are supported on the HPE ProLiant XL and HPE ProLiant DL Gen9 and Gen10 servers. They deliver up to 100Gbps bandwidth and a sub-microsecond low latency for demanding high performance computing (HPC) workloads. The adapter includes multiple offload engines that speed communications by delivering a low CPU overhead for increasing throughput. HPE InfiniBand EDR/Ethernet 2-port 841QSFP28 adapters support MPI tag matching and rendezvous offloads, along with adaptive routing on reliable transport.
$1,992
872726-B21 Technical Specifications
HPE 841QSFP28 Network Adapter PCIe 3.0 x16 100Gb Ethernet/Infiniband EDR QSFP28 x 2
Brand: HPE
Manufacture Part Number: 872726-B21
Product Line: HPE
Model: 41QSFP28
Manufacturer: HP CTO Server Avnet
Processor
Processor Type: Mellanox ConnectX-5
Processors Installed: 1
Network & Communication
Connectivity Technology: Wired
Data Link Protocols: 100 Gigabit Ethernet, 100 Gigabit InfiniBand
Data Transfer Rate: 100 GBps
Form Factor: Plug-in card
Host Interface: PCI Express 3.0 x16
Low Profile: Low profile
Product Type: Network adapter
Connectivity
Port Quantity: 2
Network & Adapter Ports: 100Gb Ethernet / Infiniband EDR QSFP28
Power
Power Consumption Operational: 16.12 watt
Technical Information
Max Operating Temperature: 131 degree Fahrenheit
Min Operating Temperature: 32 degree Fahrenheit
Operating Humidity: 5 – 95% (non-condensing)
Product Information
Capacity: Physical functions: up to 16, Virtual functions: up to 256
Physical Characteristics
Color Category: Green
