AFBR-57G5MZ-EL5 Avago 32GBPS 850NM Mmo FC Transceiver SFP+
AFBR-57G5MZ-EL5 Overview
Avago 32GBPS 850NM Mmo FC Transceiver SFP+ the Avago AFBR-57G5MZ-EL5 32GBPS 850NM Mmo Fiber Channel SFP+ Transceiver is a powerful and versatile component for high-speed data transmission. Its compatibility with multimode fiber and its compliance with industry standards make it a go-to choice for a range of applications, from data centers to telecommunications networks.
AFBR-57G5MZ-EL5 Technical Specifications
Avago 32GBPS 850NM Mmo FC Transceiver SFP+
Manufacturer: Avago
Type: Networking
Product Type: Transceiver
Technical Information of the Device
Data rate: 32 Gbps
Wavelength: 850nm
Fiber type: Multi-mode fiber (MMF)
Connector type: LC duplex
Transmission distance: Up to 150 meters on OM4 MMF
Digital diagnostics monitoring: Yes
Operating temperature range: 0°C to 70°C
Voltage supply: 3.3V
Maximum power consumption: 1W
Compliance: FC-PI-6, SFF-8472, SFP+ MSA, RoHS
